Small sample requirement
Runs a complete panel with 0.1 cc, equivalent to 100 µL, of lithium-heparinized whole blood, serum or plasma.
ABAXIS Piccolo Xpress® Chemistry Analyzer
$1,519
ABAXIS Piccolo Xpress Chemistry Analyzer — A compact point-of-care chemistry analyzer designed to deliver complete blood chemistry panels in approximately 12 minutes using only 100 µL of lithium-heparinized whole blood, serum or plasma.
Piccolo Xpress® features single-use reagent discs, integrated iQC®, a color touchscreen, built-in thermal printing and compatible LIS/EMR connectivity.
Explore Related
Related products, categories and research.
‘
Point-of-care blood chemistry
Complete chemistry panels in approximately 12 minutes
The ABAXIS Piccolo Xpress® is a compact, fully automated chemistry analyzer designed to deliver on-site blood chemistry results from only 100 µL of lithium-heparinized whole blood, serum or plasma.
100 µLSample volume
≈ 12 minResult time
5,000Stored results
Product overview
Laboratory chemistry closer to the patient
The Piccolo Xpress uses self-contained, single-use reagent discs to automate sample processing and chemistry measurement at the point of care. The operator adds the sample, inserts the disc and follows the color touchscreen prompts.
Completed results can be viewed on the display, printed using the built-in thermal printer or transferred to compatible external systems. The integrated intelligent Quality Control system, iQC®, performs automated checks during each run.
Three steps from sample to result
1
Add the sample
Transfer 100 µL of whole blood, serum or plasma to a compatible reagent disc.
2
Insert the disc
Follow the touchscreen prompts and place the disc in the analyzer drawer.
3
Review the panel
View, print or transmit the completed chemistry results in approximately 12 minutes.
Key features
Designed for fast, controlled point-of-care testing
Core capabilities based on current official ABAXIS product information.
Approximately 12 minutes
Supports same-visit review by producing a complete chemistry panel close to the patient.
Integrated iQC®
Intelligent Quality Control performs automated analyzer, reagent and sample checks during each run.
Color touchscreen
Guides the operator through analysis and displays concentrations, ranges and run information.
Built-in thermal printer
Prints results on adhesive-backed thermal paper and supports compatible external printing workflows.
External-system capable
Bi-directional input and output support compatible computers, printers and LIS or EMR workflows.
Applications
For decentralized clinical chemistry workflows
Product and panel availability depends on the destination market and local regulatory requirements.
Primary care
Routine chemistry testing during the patient visit.
Urgent care
Rapid chemistry information where routine send-out testing may delay decisions.
Hospitals and clinics
Testing in compatible outpatient units, wards and satellite locations.
Specialty care
Support for medication and treatment-monitoring workflows.
Government and field use
Compact deployment for authorized government, military and humanitarian settings.
Clinical research
Immediate chemistry data for compatible screening and monitoring protocols.
Technical specifications
Product data
Confirm regional configuration, panel menu and regulatory status before ordering.
Sample volume0.1 cc (100 µL)
Sample typesLithium-heparinized whole blood, serum or plasma
Test timeApproximately 12 minutes
Quality controlBuilt-in intelligent Quality Control (iQC®)
Consumables8 cm diameter, single-use, self-contained chemistry reagent discs
DisplayVGA color touchscreen with numeric data input
PrinterBuilt-in thermal printer with adhesive-backed paper; external printer capable
CommunicationBi-directional input and output; external computer and LIS/EMR capable
MemoryUp to 5,000 patient and quality-control results
Power100–240 V AC, 50–60 Hz; or 15 V DC, 5.0 A
Analyzer weight5.1 kg (11.2 lb)
DimensionsH 32.4 cm × W 14.9 cm × D 21.0 cm
Operating temperature15–32 °C (59–90 °F)
Operating humidity8–80%, non-condensing
Reaction temperature37 °C (98.6 °F)
Optical systemXenon arc stroboscopic lamp; detector reads nine wavelengths
Package and accessories
Configure the complete operating setup
The final quotation confirms exactly what is supplied. Reagent discs and controls are normally selected according to the required testing menu.
Base quotation
- ABAXIS Piccolo Xpress analyzer
- Manufacturer-supplied power components
- Operating and safety documentation
- Commercial invoice and shipment documentation
- Written warranty and configuration confirmation
Exact package contents vary by supplier configuration, destination and contract.
Optional consumables and accessories
- Selected Piccolo chemistry reagent panels
- Compatible quality-control materials
- Thermal printer paper and routine consumables
- Compatible barcode reader or external printer
- LIS/EMR integration support
- Voltage protection or UPS where required
Consumable storage, expiry and market authorization must be confirmed before shipment.
Official documentation
Review manufacturer resources before purchase
Official operating and quick-reference materials for technical review.
ABAXIS Resource Library
Browse current brochures, manuals, technical papers and product resources.
Installation, training and shipping
Support from quotation to clinical handover
Site-readiness review
Confirm power, bench space, environmental limits, consumable storage and data requirements.
Installation coordination
Arrange setup assistance, operational checks and documented handover where available.
Operator training
Cover sample handling, reagent discs, operation, result workflow, cleaning and first-line troubleshooting.
How much sample does the Piccolo Xpress require?
The analyzer requires 0.1 cc, equivalent to 100 µL, of lithium-heparinized whole blood, serum or plasma.
How long does a chemistry panel take?
A completed panel is available in approximately 12 minutes after analysis begins.
Does it support an LIS or EMR workflow?
Yes. The analyzer supports bi-directional input and output and is designed to work with compatible external computers, printers and LIS/EMR systems.
Are the reagent discs reusable?
No. The chemistry reagent discs are self-contained, single-use consumables designed for one sample.
Does the system include quality-control checks?
Yes. The built-in iQC® system performs automated quality checks during each run.
Can international shipping and training be included?
Yes. Shipping, export-documentation support, installation coordination and operator training can be included in the quotation, subject to destination and availability.
ABAXISA Zoetis company
Manufacturer information
Official ABAXIS product documentation
Product documentation, available reagent panels and regional regulatory information should be reviewed through official manufacturer resources before ordering.
AI Robot Supplier advantages
One procurement partner from quotation to delivery
Product review
Product identification and documentation checked before commercial confirmation.
Global logistics
Freight options, export packing and shipping documentation for approved destinations.
Project support
Configuration, consumable planning, installation coordination and operator onboarding.
Clear communication
One commercial contact for pricing, documentation, order status and delivery coordination.
Formal quotation
Request a destination-specific Piccolo Xpress quote
Include the delivery country, quantity, required reagent panels, installation needs and target purchase date.
