ZOTAC GeForce RTX 5070 Twin Edge OC White 12GB
The ZOTAC GeForce RTX 5070 Twin Edge OC White is a compact
factory-overclocked NVIDIA Blackwell graphics card with
12GB GDDR7 memory, 6,144 CUDA cores,
a 2542 MHz boost clock and manufacturer part number
ZT-B50700Q-10P.
Buyers researching the
ZOTAC RTX 5070 Twin Edge OC White price,
specifications, dimensions, power requirements or gaming performance should
verify the exact SKU before ordering. ZOTAC sells several GeForce RTX 5070
Twin Edge variants with similar names but different colours, factory clocks
and cooling configurations.
This technical buying guide covers the exact
ZT-B50700Q-10P White Edition, including GPU specifications,
1440p and 4K gaming positioning, DLSS 4, power requirements, dimensions,
display outputs, creator workloads, local AI use, package contents,
compatibility checks and international purchasing considerations.
12GB GDDR7
Graphics memory
Graphics memory
6,144
CUDA cores
CUDA cores
2542 MHz
Factory boost clock
Factory boost clock
Product overview
ZOTAC GeForce RTX 5070 Buying Overview
The ZOTAC GeForce RTX 5070 Twin Edge OC White is designed
for buyers who want current-generation RTX 5070 performance without moving
to a very large triple-fan graphics card.
Its compact dimensions make it especially relevant for white gaming PCs,
creator workstations and systems where GPU length and slot thickness are
important. ZOTAC lists the card at
241.5 × 120.1 × 40.6 mm, using a two-slot design.
The NVIDIA GeForce RTX 5070 GPU is based on the Blackwell architecture and
uses fifth-generation Tensor Cores and fourth-generation RT Cores. It also
supports the RTX 50-series software feature set including NVIDIA DLSS 4 in
compatible games and applications.
ZOTAC combines the GPU platform with IceStorm 2.0 cooling, dual 90 mm
BladeLink fans, FREEZE fan-stop technology, a metal backplate, Power Safety
Light and ZOTAC FireStorm monitoring and tuning software.
Three checks before purchase
1
Confirm the exact SKU
Your order or quotation should state
ZT-B50700Q-10P and White Edition.
2
Check case and PSU compatibility
Confirm 241.5 mm card clearance, two-slot space and suitable power
delivery for a graphics card with up to 250W listed board power.
3
Match VRAM to your workload
Confirm that 12GB GDDR7 is appropriate for your gaming, creator,
rendering or local AI requirements.
Technical highlights
ZOTAC GeForce RTX 5070 Key Features
The following features distinguish the ZT-B50700Q-10P White Edition
and are particularly important when comparing RTX 5070 graphics cards.
12GB GDDR7 graphics memory
The card includes 12GB GDDR7 VRAM operating across a
192-bit memory interface with a manufacturer-listed memory clock of
28 Gbps.
2542 MHz factory boost
The Twin Edge OC White Edition has a listed
2542 MHz boost clock, distinguishing it from the standard
non-OC Twin Edge version.
Compact two-slot design
At approximately 241.5 mm long and 40.6 mm thick, the card can fit into
systems that cannot accommodate many larger triple-fan RTX graphics cards.
IceStorm 2.0 cooling
ZOTAC uses IceStorm 2.0 cooling with dual 90 mm BladeLink fans and
FREEZE fan-stop technology to manage GPU temperatures and low-load acoustics.
NVIDIA DLSS 4
As an RTX 50-series Blackwell graphics card, the RTX 5070 supports
NVIDIA DLSS 4 features in compatible games and applications.
Applications and fit
Where the ZOTAC GeForce RTX 5070 Fits Best
The correct graphics card depends on display resolution, application
requirements, VRAM needs, chassis dimensions and available power.
1440p gaming
A strong option for buyers building a high-quality 2560 × 1440 gaming
system with support for modern ray tracing, DLSS and RTX technologies.
Compact gaming PCs
The 241.5 mm length and two-slot form factor make the Twin Edge OC White
particularly attractive where internal chassis space is limited.
Creator workstations
Compatible CUDA acceleration and NVIDIA Studio Driver support make the
GPU relevant to supported video editing, 3D rendering and creative
applications.
AI development
The card supports compatible CUDA and Tensor workloads, although
12GB VRAM should be evaluated carefully for larger local AI models.
Verified specifications
ZOTAC GeForce RTX 5070 Specifications – ZT-B50700Q-10P
The technical information below applies specifically to the
ZOTAC GAMING GeForce RTX 5070 Twin Edge OC White Edition,
manufacturer SKU ZT-B50700Q-10P.
ProductZOTAC GeForce RTX 5070 Twin Edge OC White 12GB
ManufacturerZOTAC
Manufacturer SKUZT-B50700Q-10P
GPUNVIDIA GeForce RTX 5070
ArchitectureNVIDIA Blackwell
CUDA cores6,144
AI performance988 AI TOPS
Video memory12GB GDDR7
Memory interface192-bit
Memory clock28 Gbps
Boost clock2542 MHz
PCI ExpressPCI Express 5.0 x16
Cooling systemIceStorm 2.0
FansDual 90 mm BladeLink fans
Fan-stop featureFREEZE Fan Stop
Maximum power consumption250W
Recommended PSU650W
Power input1 × 12V-2×6
Card dimensions241.5 × 120.1 × 40.6 mm
Card dimensions – inches9.5 × 4.7 × 1.6 in
Slot size2-slot
DisplayPort3 × DisplayPort 2.1b with UHBR20
HDMI1 × HDMI connector
Maximum displaysUp to four simultaneous displays
HDCP2.3
DirectXMicrosoft DirectX 12 Ultimate
OpenGLOpenGL 4.6
VulkanVulkan RT APIs / Vulkan 1.4
Driver supportNVIDIA Game Ready and NVIDIA Studio Drivers
Operating systemWindows 11 listed by ZOTAC
Performance profile
ZOTAC GeForce RTX 5070 Gaming, Creator & AI Performance
The guidance below describes the practical RTX 5070 performance class.
Actual performance depends on the processor, system memory, application,
game, resolution, graphics settings, cooling and driver version.
It is not presented as hands-on benchmark testing performed by
AI Robot Supplier.
1440p gaming
The GeForce RTX 5070 is particularly relevant to buyers targeting
high-quality 2560 × 1440 gaming.
In compatible games, NVIDIA DLSS, ray tracing and other Blackwell-generation
features can provide additional options for balancing image quality
and frame rate.
4K gaming
The RTX 5070 can be used for 4K gaming, but demanding modern titles can
require DLSS, adjusted ray-tracing settings or reduced graphics options
to achieve the desired frame rate.
The 12GB VRAM capacity should also be considered when
using very high-resolution textures or demanding ray-traced and
path-traced workloads.
Creator applications
NVIDIA Studio Driver support and CUDA acceleration make the card relevant
to compatible video editing, 3D rendering, design and GPU-accelerated
creative software.
Application-specific performance depends on software support and
the amount of GPU memory required by each project.
AI and CUDA workloads
The ZOTAC GeForce RTX 5070 can accelerate supported CUDA,
Tensor and AI applications. ZOTAC lists the GPU at
988 AI TOPS.
AI TOPS should not be interpreted as guaranteed performance for every
model or application. In practical local AI use, available VRAM is often
one of the most important constraints.
The 12GB memory capacity can work well for smaller inference,
development and AI-assisted creative workloads, while larger language
models, larger batches and advanced training projects can require GPUs
with substantially more memory.
Power & system compatibility
ZOTAC GeForce RTX 5070 PSU, Dimensions & Case Fit
650W recommended PSU
ZOTAC specifies a 650W recommended power supply for
ZT-B50700Q-10P and lists graphics-card power consumption at
250W.
The final PSU requirement also depends on the processor, motherboard,
storage, cooling hardware and other system components.
12V-2×6 power input
The card uses one 12V-2×6 power input.
Make sure the connector is fully inserted and avoid excessive cable
bending directly next to the power connector.
When using the supplied adapter, connect the required PSU cables in
accordance with the manufacturer instructions.
Compact 241.5 mm length
The graphics card measures
241.5 × 120.1 × 40.6 mm and occupies approximately
two slots.
Check usable internal case space rather than only the manufacturer’s
headline GPU-length specification. Front-mounted radiators, fans,
storage cages and vertical-mount hardware can reduce actual clearance.
Airflow remains important
The Twin Edge design is compact, but the two fans still need unobstructed
access to cool intake air.
A case with suitable front or bottom intake and clear exhaust airflow
is preferable to installing the GPU directly against a solid panel.
Displays & connectivity
ZOTAC GeForce RTX 5070 DisplayPort 2.1b & HDMI Support
3 × DisplayPort 2.1b
ZOTAC lists three DisplayPort 2.1b outputs with UHBR20 capability,
supporting modern high-resolution and high-refresh displays.
1 × HDMI output
One HDMI output is provided for compatible gaming monitors,
professional displays and televisions.
Up to four displays
The manufacturer lists support for up to four simultaneous displays.
Actual resolution and refresh combinations depend on connected hardware,
cables, DSC support and drivers.
Model comparison
ZOTAC RTX 5070 Twin Edge OC White vs Other RTX 5070 Models
The exact White Edition should be compared with related ZOTAC models
before choosing the final GPU for the system.
ZOTAC RTX 5070 Twin Edge
Standard Twin Edge configuration with 12GB GDDR7 and a lower listed
factory boost clock. Consider it when purchase price is more important
than the OC configuration.
ZOTAC RTX 5070 Twin Edge OC
Related black Twin Edge OC configuration with similar compact positioning.
A better fit if the white colour scheme is not required.
ZOTAC RTX 5070 Twin Edge OC WhiteZT-B50700Q-10P.
12GB GDDR7, 2542 MHz listed boost clock, compact dual-fan cooler and
white exterior.
12GB GDDR7, 2542 MHz listed boost clock, compact dual-fan cooler and
white exterior.
ZOTAC RTX 5070 AMP WhiteLarger premium White Edition configuration for buyers who have more
chassis room and prefer a larger cooling system.
chassis room and prefer a larger cooling system.
Buyer considerations
Important Things to Know Before Buying ZOTAC GeForce RTX 5070
- 12GB VRAM:
suitable for many gaming and creator workloads, but demanding 4K games,
large 3D scenes and larger local AI models may benefit from more GPU memory. - 650W PSU:
this is ZOTAC’s recommended PSU figure. Total system configuration may
justify additional power headroom. - Compact cooler:
the smaller two-slot format improves compatibility but still requires
appropriate chassis airflow. - 12V-2×6 connector:
verify PSU compatibility and ensure correct cable installation. - High-resolution displays:
maximum display modes depend on the monitor, cable, DSC capability
and current drivers. - Warranty:
manufacturer warranty conditions can vary according to region,
seller eligibility and product-registration requirements.
Package contents
What’s Included With ZT-B50700Q-10P?
ZOTAC’s product documentation identifies the following standard
package contents. The final order confirmation remains the authority
for the exact supplied commercial scope.
Graphics card
1 × ZOTAC GAMING GeForce RTX 5070 Twin Edge OC White Edition,
manufacturer SKU ZT-B50700Q-10P.
Power adapter
ZOTAC lists a 2 × 8-pin to 16-pin cable
with the standard product package.
User documentation
Manufacturer user manual and applicable product packaging documentation.
Order planning
ZOTAC RTX 5070 Twin Edge OC White Shipping & Warranty
International purchasing
International delivery may be available for supported destinations,
subject to current inventory, freight method, export requirements,
destination customs rules and the commercial terms of the order.
For business or quantity orders, provide the required number of units,
destination country and target delivery date so the quotation can
identify relevant commercial and delivery terms.
Warranty verification
ZOTAC warranty rules vary by country and purchase channel.
Some regional policies can include additional coverage following
eligible registration while other regions apply different conditions.
Do not assume that a manufacturer warranty published for one country
automatically applies to an international order. Confirm the applicable
coverage before completing the purchase.
Buying checklist
8 Checks Before Ordering ZOTAC GeForce RTX 5070
- Confirm manufacturer part number
ZT-B50700Q-10P. - Confirm that you require the
White Edition. - Measure at least
241.5 mm of usable graphics-card clearance. - Allow for the
40.6 mm / two-slot card width. - Confirm a suitable PSU around or above ZOTAC’s
650W recommendation. - Confirm correct
12V-2×6 power connectivity. - Determine whether
12GB VRAM is sufficient for the intended gaming,
creator or AI workload. - Confirm shipping, final supplied scope and applicable warranty terms.
Official technical documentation
ZOTAC GeForce RTX 5070 Official Resources
Use current manufacturer documentation to confirm technical
specifications, software support and configuration-sensitive information.
ZOTAC official product page
Official manufacturer page for the GeForce RTX 5070 Twin Edge OC
White Edition ZT-B50700Q-10P.
ZT-B50700Q-10P brochure
Official manufacturer brochure covering memory, clock speed,
dimensions, cooling, outputs and power requirements.
NVIDIA GeForce RTX 5070
Official NVIDIA information covering the GeForce RTX 5070 family
and NVIDIA Blackwell technologies.
Buyer questions
ZOTAC GeForce RTX 5070 FAQ
Answers to common buying questions about the
ZT-B50700Q-10P White Edition, including price, specifications,
VRAM, dimensions, PSU requirements and performance.
What is the ZOTAC GeForce RTX 5070 Twin Edge OC White?
It is a compact factory-overclocked NVIDIA GeForce RTX 5070 graphics
card manufactured by ZOTAC. The exact White Edition manufacturer part
number is ZT-B50700Q-10P.
What is the ZOTAC RTX 5070 Twin Edge OC White price?
The current selling price is displayed in the WooCommerce purchasing
area above this description. Graphics-card prices can change according
to availability, supplier inventory and quantity.
Where can I buy ZOTAC RTX 5070 Twin Edge OC White?
The ZT-B50700Q-10P White Edition can be ordered through AI Robot Supplier
when available. Business and quantity buyers can request a written
quotation for destination-specific purchasing requirements.
How much VRAM does ZT-B50700Q-10P have?
The card has 12GB GDDR7 graphics memory operating
across a 192-bit memory interface.
How many CUDA cores does the ZOTAC GeForce RTX 5070 have?
The NVIDIA GeForce RTX 5070 GPU used by ZT-B50700Q-10P has
6,144 CUDA cores.
What is the boost clock of ZT-B50700Q-10P?
ZOTAC lists a factory boost clock of
2542 MHz for the Twin Edge OC White Edition.
What PSU does the ZOTAC GeForce RTX 5070 need?
ZOTAC recommends a 650W power supply.
The graphics card itself has manufacturer-listed maximum power
consumption of 250W.
What are the ZOTAC RTX 5070 Twin Edge OC White dimensions?
The graphics card measures approximately
241.5 × 120.1 × 40.6 mm and occupies two slots.
Is the RTX 5070 good for 1440p gaming?
The RTX 5070 is well positioned for high-quality 1440p gaming.
Actual frame rates depend on the game, processor, graphics settings,
drivers, ray tracing and DLSS configuration.
Can the RTX 5070 run games at 4K?
Yes. More demanding games may require DLSS, reduced ray-tracing
settings or other graphics adjustments. The 12GB VRAM capacity should
also be considered for demanding 4K workloads.
Does the ZOTAC GeForce RTX 5070 support DLSS 4?
Yes. As an NVIDIA Blackwell RTX 50-series GPU, the GeForce RTX 5070
supports applicable DLSS 4 features in compatible games and applications.
Can ZOTAC GeForce RTX 5070 be used for AI?
Yes. It supports compatible CUDA and Tensor applications and can be used
for local AI inference and development. The practical limitation for
larger models is often the available 12GB VRAM.
How many displays can the ZOTAC RTX 5070 support?
ZOTAC lists support for up to four simultaneous displays using
three DisplayPort 2.1b outputs and one HDMI output.
What is the difference between ZT-B50700Q-10P and ZT-B50700H-10P?
ZT-B50700Q-10P is the White Edition.
ZT-B50700H-10P is the related black Twin Edge OC model.
Buyers should confirm the exact SKU when ordering.
What comes with ZT-B50700Q-10P?
ZOTAC’s manufacturer documentation lists the graphics card,
user manual and a 2 × 8-pin-to-16-pin power cable.
The final order confirmation should define the exact supplied package.
Does the ZOTAC GeForce RTX 5070 have a warranty?
Manufacturer warranty eligibility and duration vary by country,
purchase channel and applicable registration requirements.
Confirm the coverage applicable to the specific order before purchase.
Can the ZOTAC RTX 5070 Twin Edge OC White be shipped internationally?
International delivery may be arranged for supported destinations,
subject to stock availability, freight requirements, customs regulations
and the agreed commercial terms.
ZOTAC
Manufacturer / brand
Manufacturer information
ZOTAC Documentation for ZT-B50700Q-10P
Manufacturer names and trademarks are used for product identification.
Use current ZOTAC documentation to verify technical specifications,
driver compatibility and applicable regional warranty conditions.
AI Robot Supplier
Procurement Support for ZOTAC GeForce RTX 5070
The exact ZT-B50700Q-10P White Edition can be identified on the
quotation and relevant order documentation.
Quantity, pricing, supplied scope and applicable commercial terms
can be documented before order approval.
Shipping arrangements and commercial documentation can be coordinated
for supported international destinations.
Commercial buyers can request quantity pricing and destination-specific
quotations for project or enterprise purchases.
Price & availability
Buy ZOTAC GeForce RTX 5070 Twin Edge OC White 12GB
Check the current product price and availability above.
For quantity purchases, include the required number of units,
delivery country and target purchase date when requesting a
commercial quotation for ZT-B50700Q-10P.
